Where to Put a Crawl Space Dehumidifier for Even Drying

Maintaining a dry, healthy crawl space is one of the most important steps in protecting a home’s structure, air quality, and energy efficiency. But even the best dehumidifier can only deliver optimal performance if it’s placed in the right spot. The question most homeowners ask is simple:

Where should a crawl space dehumidifier be placed to ensure even drying?

With over a decade of engineering commercial-grade crawl space dehumidifiers—such as the AlorAir Sentinel HD55, Galaxy 60, Galaxy 60P, and Galaxy 85P—AlorAir has collected extensive field data on placement, airflow optimization, and correct installation practices. This PR guide brings together all essential insights, directly based on the features, airflow rates, and operating requirements of the units available on AlorAirCrawlspace.com.

Why Placement Matters

A crawl space dehumidifier works by pulling humid air across an evaporator coil, condensing moisture, and returning dry, filtered air into the area. Placement determines:

• How evenly air circulates
• How effectively moisture is removed from every corner
• Whether the unit cycles efficiently
• Noise, vibration, and stability
• Drainage performance (gravity vs pump-based)
• Filter accessibility and maintenance

If placed incorrectly—too close to a wall, blocked by insulation, or in a tight dead zone—the dehumidifier will:

• Short-cycle
• Leave pockets of moisture
• Accumulate frost more quickly
• Struggle to drain properly
• Fail to meet the humidity target

Best Locations to Place a Crawl Space Dehumidifier

Below are the most proven placement strategies based on AlorAir product engineering—airflow, CFM output, drainage design, and operating temperature.

Place the Dehumidifier in the Most Central, Open Area

To ensure even air distribution, choose a placement location that isn’t blocked by support beams, insulation, or stored materials.

Why this works

• Allows the unit’s 120–194 CFM airflow (depending on model) to circulate freely.
• Prevents moisture pockets in isolated corners.
• Enables faster drying of 1,000–2,300 sq.ft crawl spaces (based on product specs).

Recommended for all models:

• Sentinel HD55 — 113 PPD, 120 CFM
• Galaxy 60 — 145 PPD, 165 CFM
• Galaxy 60P — 145 PPD, pump drainage
• Galaxy 85P — 180 PPD, 194 CFM

Keep 12–18 Inches of Clearance Around the Unit

Every AlorAir crawl space dehumidifier uses a MERV-1 filter, rugged metal casing, and front/rear airflow design. Air must enter and exit freely.

Maintain clearance on:

• Air intake side
• Air outlet (discharge) side
• Filter access panel
• Drain hose area

Benefits

• Prevents airflow restriction
• Keeps coils from freezing
• Ensures the automatic defrost system works correctly
• Extends product lifespan

Position Near a Long Wall for Best Airflow Push

Crawl space professionals often place the dehumidifier parallel to the longest wall in the area.

Why it’s effective

• Maximizes the unit’s CFM (205–350 CMH depending on model).
• Pushes air into the full length of the crawl space.
• Ensures return airflow draws humid air from the opposite end.

Always Elevate the Unit Off the Ground

AlorAir dehumidifiers are compatible with:

• 4-inch and 6-inch heavy-duty risers
• Hanging kits for vibration reduction

Reasons to elevate

• Protects the unit from water during unexpected leaks or flooding
• Improves air intake quality
• Reduces vibration transfer to the floor
• Enhances drainage slope for gravity-dependent models (HD55, Galaxy 60)

Near the Crawl Space Access (But Not Blocking It)

You should place the dehumidifier in a spot that's easy to reach for:

• Filter changes
• Drain hose inspection
• Maintenance and troubleshooting
• Monitor panel visibility
• Firmware updates (for WiFi/App models)

AlorAir units such as the HD55S WiFi, HD35P WiFi, and HDi65S WiFi allow app-controlled monitoring, but physical access is still important.

For Pump-Equipped Models, Location Is More Flexible

Models with built-in pumps:

• Galaxy 60P — 145 PPD
• Galaxy 85P — 180 PPD

These units offer:

• Gravity drain + pump drain options
• Ability to push water vertically up and out
• Easier placement in tighter corners

Where pumps work best

• Crawl spaces with no downward slope
• Homes with higher exterior drainage exit points
• Encapsulated spaces where water must exit through floor joists or foundation walls

For Gravity-Drain Models, Placement Must Follow the Slope

Units without a pump (HD55, Galaxy 60) require a natural downward slope to move water.

Best practices

• Place the unit at the highest end of the crawl space
• Run the drain hose toward the lowest point
• Keep hose length as straight as possible
• Avoid U-shaped loops that trap water

Do Not Place a Crawl Space Dehumidifier In These Areas

Improper placement is one of the biggest reasons homeowners misinterpret performance as a “malfunction.”

Avoid:

• Directly against walls
• Tucked behind support beams
• In low pits or water-prone corners
• Immediately under plumbing leaks
• Next to insulation baffles
• In sealed dead zones
• Areas without airflow movement

Why?

• Prevent frost buildup
• Reduce coil corrosion
• Avoid stagnant air pockets
• Prevent motor overheating
• Maintain steady performance across the entire rated square footage

Should You Duct the Dehumidifier?

Many AlorAir models offer ductable outlets (especially HDi90, HDi100, HDi120 series), and ducting can help:

• Distribute dry air evenly
• Treat multiple zones
• Direct airflow into tight or encapsulated areas
• Reduce operational noise

Use ducting if:

• The crawl space is divided
• There are isolated corners
• The space is long and narrow
• You want quieter operation under living areas

Example Placement Based on AlorAir Models

Sentinel HD55 (113 PPD)

Best for:

• 1,200 sq.ft crawl spaces
• Gravity drainage installations
• Small-to-medium homes

Best placement:

• Near center or long wall
• Elevated using risers
• Aligned with the slope for drainage

Galaxy 60 (145 PPD)

Best for:

• Up to 1,800 sq.ft
• Need strong airflow (165 CFM)
• Spaces with higher humidity levels

Best placement:

• Largest open area
• Air outlet facing longest wall
• Close to drain exit

Galaxy 60P (145 PPD + Pump)

Best for:

• Homes without natural drainage slope
• Encapsulated crawl spaces
• Basements with elevated drain exits

Best placement:

• Any location with good airflow
• Pump-enabled drainage gives flexibility

Galaxy 85P (180 PPD + Pump)

Best for:

• 2,300 sq.ft large crawl spaces
• Heavy moisture removal (85 PPD @ AHAM)
• Commercial, garage, and storage applications

Best placement:

• Central and elevated
• Maintain large clearance for airflow
• Avoid dead corners due to high CFM output (194 CFM)

Additional Tips for Even Drying

Use the following strategies to ensure full-area moisture control:

• Seal major air leaks before running the unit

Reduces new moisture infiltration.

• Combine with a vapor barrier

AlorAir sells 10 mil / 12 mil vapor barrier film which prevents ground moisture.

• Use a remote controller

Available for HD35P, HD55, HDi65S, etc.

• Pair with a crawl space ventilator

AlorAir VentirPro can help manage fresh air flow.

• Set humidity between 45–55%

All AlorAir units support 36–90% humidity range.

Conclusion: Correct Placement = Maximum Performance

Every crawl space is unique, but the fundamentals of placement remain the same. Whether you choose the compact Sentinel HD55, the efficient Galaxy 60, the pump-powered Galaxy 60P, or the high-capacity Galaxy 85P, proper placement ensures:

• Even air circulation
• Faster drying
• Lower energy use
• Fewer moisture pockets
• Longer equipment lifespan

A well-placed dehumidifier transforms a damp, musty crawl space into a dry, fresh, structurally protected environment. When installed correctly, an AlorAir unit delivers professional-grade drying power—built with rugged metal casings, automatic defrost systems, corrosion-resistant coils, and long warranties backed by U.S-based support.

For homeowners, contractors, or restoration professionals, choosing the right location is just as important as choosing the right dehumidifier. With proper placement, every AlorAir unit performs at its highest level—ensuring long-lasting comfort and protection for the home.
